YMC
YMC-Pack CN
◈ Product Information
Most Polar Reversed-Phase Column
In a reversed-phase mode, Cyano columns are the most polar and least retentive of all reversed-phase packings.
Extremely hydrophobic compounds, which do not elute on standard C18 and C8 packings with typical reversed-phase eluents, can be chromatographed using Cyano columns.
In addition, the unique nitrile chemistry provides different selectivity from both phenyl and standard aliphatic (C18, C8 and C4) reversed-phase packing. Large pore size 300Å packing materials are also available for the analysis of biomolecules.
Alternative to Silica
In a normal phase mode, Cyano is a bonded phase alternative to silica. Bonded normal phase columns have the advantage of faster equilibration and more uniform surface activity than bare silica gel. To extend column life, continued switching back and forth between normal and reversed phase solvents should be avoided.
► Point
• Useful in both normal and reversed-phase applications
• Stable high coverage monomerically bonded phase
• Fully endcapped
• Available in spherical 3, 5, 10, 15 and 20µm
• Analytical, semi-prep and preparative column sizes available
► Specification
- Particle size :3㎛, 5㎛, 10㎛
- Pore size :120A, 300A
- Carbon contents :7%, 3%
- Usable pH range :2.0-7.5
| Normal Phase mode - Reversed Phase mode |
Useful in both normal and reversed-phase mode. Elution sequence is reversed by the difference of separation mode.
◈ Ordering Information
|
YMC-Pack CN Analytical Columns | |||
|---|---|---|---|
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-3 |
120 |
2.0 X 35 |
CN12S03-H502WT |
|
2.0 X 50 |
CN12S03-0502WT | ||
|
2.0 X 75 |
CN12S03-L502WT | ||
|
2.0 X 100 |
CN12S03-1002WT | ||
|
2.0 X 150 |
CN12S03-1502WT | ||
|
3.0 X 50 |
CN12S03-0503WT | ||
|
3.0 X 100 |
CN12S03-1003WT | ||
|
3.0 X 150 |
CN12S03-1503WT | ||
|
4.6 X 100 |
CN12S03-1046WT | ||
|
4.6 X 150 |
CN12S03-1546WT | ||
|
S-5 |
120 |
1.0 X 150 |
CN12S05-1501WT |
|
1.0 X 250 |
CN12S05-2501WT | ||
|
1.5 X 150 |
CN12S05-15P5WT | ||
|
1.5 X 250 |
CN12S05-25P5WT | ||
|
2.0 X 150 |
CN12S05-1502WT | ||
|
2.0 X 250 |
CN12S05-2502WT | ||
|
4.6 X 75 |
CN12S05-L546WT | ||
|
4.6 X 100 |
CN12S05-1046WT | ||
|
4.6 X 150 |
CN12S05-1546WT | ||
|
4.6 X 250 |
CN12S05-2546WT | ||
|
4.6 X 300 |
CN12S05-3046WT | ||
|
6.0 X 100 |
CN12S05-1006WT | ||
|
6.0 X 150 |
CN12S05-1506WT | ||
|
6.0 X 250 |
CN12S05-2506WT | ||
|
6.0 X 300 |
CN12S05-3006WT | ||
|
300 |
1.0 X 150 |
CN30S05-1501WT | |
|
1.0 X 250 |
CN30S05-2501WT | ||
|
1.5 X 150 |
CN30S05-15P5WT | ||
|
1.5 X 250 |
CN30S05-25P5WT | ||
|
2.0 X 150 |
CN30S05-1502WT | ||
|
2.0 X 250 |
CN30S05-2502WT | ||
|
4.6 X 75 |
CN30S05-L546WT | ||
|
4.6 X 100 |
CN30S05-1046WT | ||
|
4.6 X 150 |
CN30S05-1546WT | ||
|
4.6 X 250 |
CN30S05-2546WT | ||
|
4.6 X 300 |
CN30S05-3046WT | ||
|
6.0 X 100 |
CN30S05-1006WT | ||
|
6.0 X 150 |
CN30S05-1506WT | ||
|
6.0 X 250 |
CN30S05-2506WT | ||
|
6.0 X 300 |
CN30S05-3006WT | ||
|
S-10 |
120 |
4.6 X 100 |
CN12S11-1046WT |
|
4.6 X 150 |
CN12S11-1546WT | ||
|
4.6 X 250 |
CN12S11-2546WT | ||
|
4.6 X 300 |
CN12S11-3046WT | ||
|
6.0 X 100 |
CN12S11-1006WT | ||
|
6.0 X 150 |
CN12S11-1506WT | ||
|
6.0 X 250 |
CN12S11-2506WT | ||
|
6.0 X 300 |
CN12S11-3006WT | ||
|
YMC-Pack CN Semi-preparative Columns | |||
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-5 |
120 |
10 X 150 |
CN12S05-1510WT |
|
10 X 250 |
CN12S05-2510WT | ||
|
10 X 300 |
CN12S05-3010WT | ||
|
20 X 100 |
CN12S05-1020WT | ||
|
20 X 150 |
CN12S05-1520WT | ||
|
20 X 250 |
CN12S05-2520WT | ||
|
300 |
20 X 150 |
CN30S05-1520WT | |
|
20 X 250 |
CN30S05-2520WT | ||
|
S-10 |
120 |
10 X 150 |
CN12S11-1510WT |
|
10 X 250 |
CN12S11-2510WT | ||
|
10 X 300 |
CN12S11-3010WT | ||
|
20 X 150 |
CN12S11-1520WT | ||
|
20 X 250 |
CN12S11-2520WT | ||
|
YMC-Pack CN Guard Cartridge Columns | |||
|
Particle size |
Pore size |
Column size Inner diameter |
Product Number |
|
S-3 |
120 |
2.0 X 10 |
CN12S03-0102CC |
|
4.0 X 23 |
CN12S03-G304CC | ||
|
S-5 |
120 |
1.0 X 10 |
CN12S05-0101CC |
|
1.5 X 10 |
CN12S05-01P5CC | ||
|
2.0 X 10 |
CN12S05-0102CC | ||
|
4.0 X 23 |
CN12S05-G304CC | ||
|
300 |
1.0 X 10 |
CN30S05-0101CC | |
|
1.5 X 10 |
CN30S05-01P5CC | ||
|
2.0 X 10 |
CN30S05-0102CC | ||
|
4.0 X 23 |
CN30S05-G304CC | ||
*When using it for the first time,please purchase the cartridge holder corresponding to inner diameter of column.
|
YMC-Pack CN Cartridge Holder | |||
|---|---|---|---|
|
|
Product Number | ||
|
Semi Micro Guard Cartridge Holder(Inner diameter 1.0,1.5,2.0mm) |
XPCHSMW | ||
|
Cartridge Holder (Inner diameter 4.0mm) |
XPCHW | ||
|
YMC-Pack CN Guard Columns | |||
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-5 |
120 |
4.0 X 10 |
CN12S05-0104WFG |
|
5.0 X 10 |
CN12S05-0105WFG | ||
|
10 X 30 |
CN12S05-0310WTG | ||
|
20 X 50 |
CN12S05-0520WTG | ||
|
300 |
4.0 X 10 |
CN30S05-0104WFG | |
|
5.0 X 10 |
CN30S05-0105WFG | ||
|
10 X 30 |
CN30S05-0310WTG | ||
|
20 X 50 |
CN30S05-0520WTG | ||
|
S-10 |
120 |
4.0 X 10 |
CN12S11-0104WFG |
|
5.0 X 10 |
CN12S11-0105WFG | ||
|
10 X 30 |
CN12S11-0310WTG | ||
|
20 X 50 |
CN12S11-0520WTG | ||
