YMC CHIRAL NEA
◈ Product Information
YMC CHIRAL NEA(R) and (S) phase optical isomer separation columns. Chiral discrimination is based on the higher-order structure of chiral macromolecules, which includes hydrogen bonds, π-π interaction, hydrophobic interaction, etc.
► Point
• Synthesized macromolecule-type chiral column
• Elution order can be reversed by selecting (R) or (S)
• Excellent cost performance
► Specification
- Particle size :5㎛
- Usable pH range :2.0-6.5
|
Used with reversed phase eluent |
◈ Ordering Information
|
YMC CHIRAL NEA Analytical Columns for Reversed-phase | ||||
|---|---|---|---|---|
|
YMC*Gel |
Particle size |
Pore size(Å) |
Column size Inner diameter |
Product Number |
|
NEA(R) |
S-5 |
300 |
4.6 X 150 |
NR30S05-1546WT |
|
4.6 X 250 |
NR30S05-2546WT | |||
|
NEA(S) |
S-5 |
300 |
4.6 X 150 |
NS30S05-1546WT |
|
4.6 X 250 |
NS30S05-2546WT | |||
|
YMC CHIRAL NEA Analytical Columns for Normal-phase | ||||
|
YMC*Gel |
Particle size |
Pore size(Å) |
Column size Inner diameter |
Product Number |
|
NEA(R) |
S-5 |
300 |
4.6 X 150 |
CR30S05-1546WT |
|
4.6 X 250 |
CR30S05-2546WT | |||
|
NEA(S) |
S-5 |
300 |
4.6 X 150 |
CS30S05-1546WT |
|
4.6 X 250 |
CS30S05-2546WT | |||
|
YMC CHIRAL NEA Guard Cartridge Columns for Reversed-phase | ||||
|
YMC*Gel |
Particle size |
Pore size(Å) |
Column size Inner diameter |
Product Number |
|
NEA(R) |
S-5 |
300 |
4.0 X 23 |
NR30S05-G304CC |
|
NEA(S) |
S-5 |
300 |
4.0 X 23 |
NS30S05-G304CC |
| *When using it for the first time,please purchase the cartridge holder corresponding to inner diameter of column. |
|
YMC CHIRAL NEA Guard Cartridge Columns for Normal-phase | ||||
|---|---|---|---|---|
|
YMC*Gel |
Particle size |
Pore size(Å) |
Column size Inner diameter |
Product Number |
|
NEA(R) |
S-5 |
300 |
4.0 X 23 |
CR30S05-G304CC |
|
NEA(S) |
S-5 |
300 |
4.0 X 23 |
CS30S05-G304CC |
| *When using it for the first time,please purchase the cartridge holder corresponding to inner diameter of column. |
|
YMC NEA Cartridge Holder | |
|
|
Product Number |
|
Cartridge Holder (Inner diameter 4.0mm) |
XPCHW |
