YMC
YMC-Pack C8
◈ Product Information
Monomerically Bonded Octyl, Fully Endcapped
C8 is the most commonly used column type following C18. YMC Octyl columns are prepared from exhaustive bonding of a monomeric octylsilane to totally spherical and porous silica gels. The functionalized silica is then treated with a endcapping process. This produces a moderate 10% carbon loading on the standard 120Å pore material.
Broad Application Range
C8 columns are well suited for the separation of many compounds which are too strongly retained on C18 phases or require greater retention than C4. It is the most versatile reversed phase column and should be considered a first choice when outfitting a new laboratory.
Three Pore sizes Available
Available in three pore size, YMC Octyl columns will separate many classes of compounds including pharmaceuticals, organic chemicals and biologicals. For preparative applications, choose the smallest pore size which provides adequate retention and resolution. This is because sample loading is generally proportional to surface area. Small pore packings provide greater surface area.
► Point
• Choice of 120Å, 200Å or 300Å pore sizes
• Fully endcapped
• High coverage monomeric bonded chemistry
• Available in analytical, semi preparative and preparative column sizes
► Specification
- Particle size :3㎛, 5㎛, 10㎛
- Pore size :120A, 200A, 300A
- Carbon contents :10%, 7%, 4%
- Usable pH range :2.0-7.5
◈ Ordering Information
|
YMC-Pack C8 Analytical Columns | |||
|---|---|---|---|
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-3 |
120 |
2.0 X 35 |
OC12S03-H502WT |
|
2.0 X 50 |
OC12S03-0502WT | ||
|
2.0 X 75 |
OC12S03-L502WT | ||
|
2.0 X 100 |
OC12S03-1002WT | ||
|
2.0 X 150 |
OC12S03-1502WT | ||
|
3.0 X 50 |
OC12S03-0503WT | ||
|
3.0 X 100 |
OC12S03-1003WT | ||
|
3.0 X 150 |
OC12S03-1503WT | ||
|
4.6 X 100 |
OC12S03-1046WT | ||
|
4.6 X 150 |
OC12S03-1546WT | ||
|
S-5 |
120 |
1.0 X 150 |
OC12S05-1501WT |
|
1.0 X 250 |
OC12S05-2501WT | ||
|
1.5 X 150 |
OC12S05-15P5WT | ||
|
1.5 X 250 |
OC12S05-25P5WT | ||
|
2.0 X 150 |
OC12S05-1502WT | ||
|
2.0 X 250 |
OC12S05-2502WT | ||
|
4.6 X 75 |
OC12S05-L546WT | ||
|
4.6 X 100 |
OC12S05-1046WT | ||
|
4.6 X 150 |
OC12S05-1546WT | ||
|
4.6 X 250 |
OC12S05-2546WT | ||
|
4.6 X 300 |
OC12S05-3046WT | ||
|
6.0 X 100 |
OC12S05-1006WT | ||
|
6.0 X 150 |
OC12S05-1506WT | ||
|
6.0 X 250 |
OC12S05-2506WT | ||
|
6.0 X 300 |
OC12S05-3006WT | ||
|
200 |
4.6 X 150 |
OC20S05-1546WT | |
|
4.6 X 250 |
OC20S05-2546WT | ||
|
300 |
1.0 X 150 |
OC30S05-1501WT | |
|
1.0 X 250 |
OC30S05-2501WT | ||
|
1.5 X 150 |
OC30S05-15P5WT | ||
|
1.5 X 250 |
OC30S05-25P5WT | ||
|
2.0 X 150 |
OC30S05-1502WT | ||
|
2.0 X 250 |
OC30S05-2502WT | ||
|
4.6 X 75 |
OC30S05-L546WT | ||
|
4.6 X 100 |
OC30S05-1046WT | ||
|
4.6 X 150 |
OC30S05-1546WT | ||
|
4.6 X 250 |
OC30S05-2546WT | ||
|
4.6 X 300 |
OC30S05-3046WT | ||
|
6.0 X 100 |
OC30S05-1006WT | ||
|
6.0 X 150 |
OC30S05-1506WT | ||
|
6.0 X 250 |
OC30S05-2506WT | ||
|
6.0 X 300 |
OC30S05-3006WT | ||
|
S-10 |
120 |
4.6 X 100 |
OC12S11-1046WT |
|
4.6 X 150 |
OC12S11-1546WT | ||
|
4.6 X 250 |
OC12S11-2546WT | ||
|
4.6 X 300 |
OC12S11-3046WT | ||
|
6.0 X 100 |
OC12S11-1006WT | ||
|
6.0 X 150 |
OC12S11-1506WT | ||
|
6.0 X 250 |
OC12S11-2506WT | ||
|
6.0 X 300 |
OC12S11-3006WT | ||
|
300 |
4.6 X 100 |
OC30S11-1046WT | |
|
4.6 X 150 |
OC30S11-1546WT | ||
|
4.6 X 250 |
OC30S11-2546WT | ||
|
4.6 X 300 |
OC30S11-3046WT | ||
|
6.0 X 100 |
OC30S11-1006WT | ||
|
6.0 X 150 |
OC30S11-1506WT | ||
|
6.0 X 250 |
OC30S11-2506WT | ||
|
6.0 X 300 |
OC30S11-3006WT | ||
|
YMC-Pack C8 Semi-preparative Columns | |||
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-5 |
120 |
10 X 150 |
OC12S05-1510WT |
|
10 X 250 |
OC12S05-2510WT | ||
|
10 X 300 |
OC12S05-3010WT | ||
|
20 X 100 |
OC12S05-1020WT | ||
|
20 X 150 |
OC12S05-1520WT | ||
|
20 X 250 |
OC12S05-2520WT | ||
|
200 |
20 X 150 |
OC20S05-1520WT | |
|
20 X 250 |
OC20S05-2520WT | ||
|
300 |
10 X 150 |
OC30S05-1510WT | |
|
10 X 250 |
OC30S05-2510WT | ||
|
10 X 300 |
OC30S05-3010WT | ||
|
20 X 150 |
OC30S05-1520WT | ||
|
20 X 250 |
OC30S05-2520WT | ||
|
S-10 |
120 |
10 X 150 |
OC12S11-1510WT |
|
10 X 250 |
OC12S11-2510WT | ||
|
10 X 300 |
OC12S11-3010WT | ||
|
20 X 150 |
OC12S11-1520WT | ||
|
20 X 250 |
OC12S11-2520WT | ||
|
200 |
20 X 150 |
OC20S11-1520WT | |
|
20 X 250 |
OC20S11-2520WT | ||
|
300 |
10 X 150 |
OC30S11-1510WT | |
|
10 X 250 |
OC30S11-2510WT | ||
|
10 X 300 |
OC30S11-3010WT | ||
|
20 X 150 |
OC30S11-1520WT | ||
|
20 X 250 |
OC30S11-2520WT |
||
|
YMC-Pack C8 Guard Cartridge Columns | |||
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-3 |
120 |
2.0 X 10 |
OC12S03-0102CC |
|
4.0 X 23 |
OC12S03-G304CC | ||
|
S-5 |
120 |
1.0 X 10 |
OC12S05-0101CC |
|
1.5 X 10 |
OC12S05-01P5CC | ||
|
2.0 X 10 |
OC12S05-0102CC | ||
|
4.0 X 23 |
OC12S05-G304CC | ||
|
200 |
4.0 X 23 |
OC20S05-G304CC | |
|
300 |
1.0 X 10 |
OC30S05-0101CC | |
|
1.5 X 10 |
OC30S05-01P5CC | ||
|
2.0 X 10 |
OC30S05-0102CC | ||
|
4.0 X 23 |
OC30S05-G304CC | ||
| *When using it for the first time,please purchase the cartridge holder corresponding to inner diameter of column. |
|
YMC-Pack C8 Cartridge Holder | |||
|---|---|---|---|
|
|
Product Number | ||
|
Semi Micro Guard Cartridge Holder(Inner diameter 1.0,1.5,2.0mm) |
XPCHSMW | ||
|
Cartridge Holder (Inner diameter 4.0mm) |
XPCHW | ||
|
YMC-Pack C8 Guard Columns | |||
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-5 |
120 |
4.0 X 10 |
OC12S05-0104WFG |
|
5.0 X 10 |
OC12S05-0105WFG | ||
|
10 X 30 |
OC12S05-0310WTG | ||
|
20 X 50 |
OC12S05-0520WTG | ||
|
200 |
4.0 X 10 |
OC20S05-0104WFG | |
|
20 X 50 |
OC20S05-0520WTG | ||
|
300 |
4.0 X 10 |
OC30S05-0104WFG | |
|
5.0 X 10 |
OC30S05-0105WFG | ||
|
10 X 30 |
OC30S05-0310WTG | ||
|
20 X 50 |
OC30S05-0520WTG | ||
|
S-10 |
120 |
4.0 X 10 |
OC12S11-0104WFG |
|
5.0 X 10 |
OC12S11-0105WFG | ||
|
10 X 30 |
OC12S11-0310WTG | ||
|
20 X 50 |
OC12S11-0520WTG | ||
|
200 |
20 X 50 |
OC20S11-0520WTG | |
|
300 |
4.0 X 10 |
OC30S11-0104WFG | |
|
5.0 X 10 |
OC30S11-0105WFG | ||
|
10 X 30 |
OC30S11-0310WTG | ||
|
20 X 50 |
OC30S11-0520WTG | ||
