YMC-Pack TMS
◈ Product Information
YMC-Pack TMS columns are bonded with trimethylmonochlorosilane to create a phase with intermediate polarity for analysis of extremely hydrophobic compounds using conventional reversed-phase solvents and highly polar compounds using highly aqueous solvents. The unique chemistry of TMS is also well-suited for the analysis of multifunctional compounds. Selectivity characteristics of a C1 bonded phase can be unique and samples must be tested to determine the applicability of the phase.
► Point
• Shortest of all alkyl bonded phases
• Intermediate polarity between normal phase silica and other alkyl bonded reversed phases
• Available in analytical, semi-perp and preparative column sizes
► Specification
- Particle size :3㎛, 5㎛, 10㎛
- Pore size :120A
- Carbon contents :4%
- Usable pH range :2.0-7.5
◈ Ordering Information
|
YMC-Pack TMS Analytical Columns | |||
|---|---|---|---|
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-3 |
120 |
4.6 X 100 |
TM12S03-1046WT |
|
4.6 X 150 |
TM12S03-1546WT | ||
|
S-5 |
120 |
1.0 X 150 |
TM12S05-1501WT |
|
1.0 X 250 |
TM12S05-2501WT | ||
|
1.5 X 150 |
TM12S05-15P5WT | ||
|
1.5 X 250 |
TM12S05-25P5WT | ||
|
2.0 X 150 |
TM12S05-1502WT | ||
|
2.0 X 250 |
TM12S05-2502WT | ||
|
4.6 X 75 |
TM12S05-L546WT | ||
|
4.6 X 100 |
TM12S05-1046WT | ||
|
4.6 X 150 |
TM12S05-1546WT | ||
|
4.6 X 250 |
TM12S05-2546WT | ||
|
4.6 X 300 |
TM12S05-3046WT | ||
|
6.0 X 100 |
TM12S05-1006WT | ||
|
6.0 X 150 |
TM12S05-1506WT | ||
|
6.0 X 250 |
TM12S05-2506WT | ||
|
6.0 X 300 |
TM12S05-3006WT | ||
|
S-10 |
120 |
4.6 X 100 |
TM12S11-1046WT |
|
4.6 X 150 |
TM12S11-1546WT | ||
|
4.6 X 250 |
TM12S11-2546WT | ||
|
4.6 X 300 |
TM12S11-3046WT | ||
|
6.0 X 100 |
TM12S11-1006WT | ||
|
6.0 X 150 |
TM12S11-1506WT | ||
|
6.0 X 250 |
TM12S11-2506WT | ||
|
6.0 X 300 |
TM12S11-3006WT | ||
|
YMC-Pack TMS Semi-preparative Columns | |||
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-5 |
120 |
10 X 150 |
TM12S05-1510WT |
|
10 X 250 |
TM12S05-2510WT | ||
|
10 X 300 |
TM12S05-3010WT | ||
|
20 X 100 |
TM12S05-1020WT | ||
|
20 X 150 |
TM12S05-1520WT | ||
|
20 X 250 |
TM12S05-2520WT | ||
|
S-10 |
120 |
10 X 150 |
TM12S11-1510WT |
|
10 X 250 |
TM12S11-2510WT | ||
|
10 X 300 |
TM12S11-3010WT | ||
|
20 X 150 |
TM12S11-1520WT | ||
|
20 X 250 |
TM12S11-2520WT | ||
|
YMC-Pack TMS Guard Cartridge Columns | |||
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-3 |
120 |
4.0 X 23 |
TM12S03-G304CC |
|
S-5 |
120 |
1.0 X 10 |
TM12S05-0101CC |
|
1.5 X 10 |
TM12S05-01P5CC | ||
|
2.0 X 10 |
TM12S05-0102CC | ||
|
4.0 X 23 |
TM12S05-G304CC | ||
| *When using it for the first time,please purchase the cartridge holder corresponding to inner diameter of column. |
|
YMC-Pack TMS Cartridge Holder | |||
|---|---|---|---|
|
|
Product Number | ||
|
Semi Micro Guard Cartridge Holder(Inner diameter 1.0,1.5,2.0mm) |
XPCHSMW | ||
|
Cartridge Holder (Inner diameter 4.0mm) |
XPCHW | ||
|
YMC-Pack TMS Guard Columns | |||
|
Particle size |
Pore size |
Column size Inner diameter x length |
Product Number |
|
S-5 |
120 |
4.0 X 10 |
TM12S05-0104WFG |
|
5.0 X 10 |
TM12S05-0105WFG | ||
|
10 X 30 |
TM12S05-0310WTG | ||
|
20 X 50 |
TM12S05-0520WTG | ||
|
S-10 |
120 |
4.0 X 10 |
TM12S11-0104WFG |
|
5.0 X 10 |
TM12S11-0105WFG | ||
|
10 X 30 |
TM12S11-0310WTG | ||
|
20 X 50 |
TM12S11-0520WTG | ||
