EXL®7 Lab Water System Pure & Ultrapure Water Quality


 Ultrapure

 Series

 EXL®7 Analysis

 Resistivity (at 25℃)

 18.2 MΩxcm

 *TOC

 <5 ppb

 **Bacteria

<0.01 CFU/mL

 Endotoxin

-

 RNases  (RNase-free)

-

 DNases  (DNase-free)

-

 Particles  (@0.2 )

 <1/mL

 Flow Rate

  Up to 2(I/min)

 RO Module Rejection Rates (Pure)

 Resistivity (at 25℃)

-

 Monovalent Ions (%)

Up to 98%

 Polyvalent Ions (%)

Up to 98%

 Particles

>99%

 Microorga-nisms

>99%

 Dissolved Organics (>300MW)

>99%

 Product Flow Rate(±20% at 25℃)

 Up to 16/32 l/h

 Maximum Recovery Rate*

Approxi. 50 %


Depends on feed water quality and temperature.

* TOC Specs - Test Conditions:

  EXL®System equipped with Pre Carbon filter and DI cartridge and with feed(tap) water quality within

  pecifications. Product water quality may vary due to local feed water conditions.


** Results with 0.2 Final Filter.


 Feed Water Quality

* Exclusively potable water according to the drinking water regulations of the USA, the European Union, Korea or Japan.


 Temperature

 2-30

 Conductivity

 <500 /cm

 TDS

 <250 ppm

 TOC

 <2000 ppb

 Max. Permanent Hardness(max.CaCO3)

360 ppm

 Free chlorine

3 ppm

 Iron (Total Fe Content)

<0.1 ppm

 Fouling Index

 <5 SDI

 Turbidity

 <1 NTμ

 pH Value

  4-10

 Input Pressure

  0.5-6.9bar, Recommended >2bar
